Cable Assemblies/Wire Harness
Overview | Advantages | Capabilities
Overview
Alpine can provide custom cables to your specifications - just bring us your concepts or design ideas and we will work quickly to deliver an economic solution without compromising quality. We also provide innovative solutions designed for performance, reliability and ease of installation.
Alpine is a leader in providing a full array of custom cable assembly products including wiring harnesses, coax and molded assemblies. Our technical staff can work with you on the design to meet performance objectives and manufacturing cost targets.
Success Stories
- Designed, source and currently supplying many custom cable assemblies to the major supplier of security cameras in the world
- Designed, source and deliver a custom custom cable assembly with a terminal block output connection and ESD protection to an emergency door release sytem supplier
- Source and deliver a custom cable assembly to a manufacturer of industrial weighing systems
Unique Advantages
- Working with cable assembly technology leaders
- Engineering and new product capabilities (NPI)
- Quick-turn to high volume manufacturing
- Global low cost manufacturing capabilities
As an ISO 9002 and TS16949 certified production facility, our customers benefit from a total commitment to quality manufacturing. In addition to assembly, many key manufacturing processes are done in-house including injection molding, stamping and raw cable manufacturing to ensure excellent process control. To guarantee final product quality, custom cables are checked 100 percent for continuity and point-to-point.
Additional cable performance tests can be provided at customer's request.
Manufacturing Capabilities
-
Overmolding
-
Termination Techniques
- Insulation Displacement
- Crimp Snap
- Wire In Slot
- Hand soldering
- Pad printing and labeling
- Custom packaging
- Sub-Assembly Integration
Examples of Types of Cables Available
- Jacketed Cable Assemblies
- Miniature Jacketed Coax Cable Assemblies
- Wire Harnesses
- RF Coax Assemblies
- High Performance Video Cable Assemblies
